使用用途与百科/Brief Introduction：

滤油机是转化成原浆、油类液波璃瓶的新产品，恢复改善了已往原浆、油类液波璃瓶的欠佳特效。这类的灌封机所配的朔胶瓶，不仅仅不所需洗瓶机、烘干阶段机，更不所需进行消毒，可以马上灌封。这个机器全手动理瓶、进瓶、罐装，罐装量平稳的，无漏滴，无瓶不罐装。上盖、粘口率多达100%。此机技木比较好的，体型大小小、运作平稳的、燥声低，的操作修补、清洁更方便等性能，全不符合GMP规格。This machine is a new product instead of oral liquid bottles, thoroughly solved before the adverse effect of oral liquid glass bottle. The used plastic bottles, filling and sealing machine not only don't need to bottle washer, dryer, more don't need disinfection, can be directly potting. The machine is fully automatic unscramble bottle, bottle feeding, filling, filling volume stability, no LouDi, no bottle no filling. Cover and sealing rate can reach 100%. This machine technology is advanced, small volume, stable running, low noise, convenient operation and maintenance, cleaning, etc, in full compliance with GMP standard.注：本尺寸有慢速和快速二者销售量供您选。Note: this model has two kinds of low speed and high-speed production for your choice.

特色 Characteristic

◆滤油机采使用在各种各样的易折瓶液体液收费灌装线和封口处。The machine is suitable for all kinds of folding bottles of oral liquid filling and sealing of measurement.◆大多数电器设备元器件封装均适用着时尚品牌排行牌。All electrical components adopt famous brand◆该机方法准确有利，无瓶不灌装生产线，计量检验*。It has intuitive and convenient operation, no bottle no filling, measuring precision.◆易折氟塑料瓶子灌封机的主要的结构特征与的工作原理Easy to fold the main structure and principle of plastic bottle filling and sealing machine◆NFGFY型冲剂液易折泡沫塑料瓶子灌封机包括理瓶器、理盖器、主齿轮变速箱平台、发送到带时候送单瓶置、玻璃瓶子检漏试验系统、包装单位、删去试验系统、热熔胶封单位、液压物理手指头夹瓶单位、步进驱动器高压电机时候上瓶单位与出瓶单位等组成部分。Type NFGFY oral liquid is easy to fold the plastic bottle filling and sealing machine main GaiQi bottle opener, and the main transmission system, the synchronous belt clearance to send bottle device, empty bottle leak detection device, filling body, eliminating device, hot melt sealing mechanism, pneumatic mechanical fingers bottle gap on the bottle structure, servo motor and a bottle of institutions, etc.◆系统施用的口服方式液易折朔胶瓶、盖有的是定洁净度区加工的，应当药粉材可证证，故此瓶身与底盖经引入和"去开发"后可就直接加入灌封间。完成理盖器、理瓶器的自然专向整理出来，清除单向底盖及瓶身底口朝下的瓶，使专向后的包材喂料有要求地加入气力输送机道路中。Machine using oral liquid is easy to fold the plastic bottles, cover a certain production of clean area, should have the medicine packaging material license, so the bottle and the bottom cover after transfer and "outsourcing" can go directly into the potting. By Richard GaiQi, automatic directional arrangement of bottle opener, eliminate reverse bottom cover and the bottom of the bottle mouth bottle at the bottom, after making the orientation of packaging material feeding regularly into orbit. ◆定向分配后口服药液易折塑胶片瓶在气流输送轨道交通里排Directional oral liquid after folding plastic bottles in conveying rail out easily

系统参数值technical parameters：

型号model	NLGFY-40	NLGFY-80
装量空间The load range	5-100ML
生产能力production capacity	20-40瓶/分	50-80瓶/分
密封率Hot sealing intensity	》99%
装量出现偏差的原因The load error	《1.5%
损坏率damage rate	《1.0%
电率power	2KW	3KW
供电Power Supply	380V 50Hz/220V 50Hz
外形尺寸boundary dimension	2700*1100*1900mm	3000*1480*1900mm
体积 Weight	700Kg	800Kg
